The 105 tooth, MOD 0.8 gear will mate with any MOD 0.8 gear. However when building on pattern, the most common partner for this gear is a 15 tooth pinion gear or servo gear. Utilizing a pinion gear you can create a 7:1 underdrive or overdrive setup depending on your application. When used with the 15 tooth servo gear, this combo creates a 7:1 underdrive, slowing the final speed while increasing the torque by 7x.
Specs
| Weight | 38g |
|---|---|
| Material | Aluminum |
| Finish | Clear Anodized |
| Tooth Count | 105 |
| Gear Pitch | MOD 0.8 |
| Pressure Angle | 20 Degree |
